Like all Reverse Osmosis Systems manufactured in the USA by US Water Systems, we source as many components as possible from American Manufacturers. Our frames, filter housings, filters, membranes, tanks and the like are all sourced from American Companies. Our systems are also assembled in the USA by American Craftsmen (and Craftswomen).
100% BPA Free - Here's Why
BPA (bisphenol A) is a chemical that is added to many commercial products, including food containers and hygiene products. It was first discovered in the 1890s, but chemists in the 1950s realized that it could be mixed with other compounds to produce strong and resilient plastics.
BPA is said to mimic the structure and function of the hormone estrogen. Due to its estrogen-like shape, BPA can bind to estrogen receptors and influence bodily processes, such as growth, cell repair, fetal development, energy levels, and reproduction. In addition, BPA may also interact with other hormone receptors, such as those for your thyroid, thus altering their function.
Your body is sensitive to changes in hormone levels, which is the reason why BPA's ability to mimic estrogen is believed to affect your health.
Contaminant | Reduction |
Algae | 99.90% |
Aluminum | 98.00% |
Amoebic Cysts | 99.00% |
Arsenic | 95.00% |
Asbestos | 99.00% |
Atrazine | 95.00% |
Bacteria | 95.00% |
Barium | 97.00% |
Calcium | 99.50% |
Chloride | 95.00% |
Chlorine | 99.90% |
Chromate | 94.50% |
Copper | 99.00% |
Cryptosporidium Cysts | 97.00% |
Cyanide | 97.00% |
Fluoride | 98.00% |
Giardia Lamblia Cysts | 99.00% |
Lead | 97.00% |
Manganese | 98.00% |
Magnesium | 97.00% |
Contaminant | Reduction |
Mercury | 98.00% |
Mold | 99.90% |
Nickel | 95.00% |
Nitrate | 89.00% |
Phosphate | 95.00% |
Potassium | 95.00% |
Protozoa | 99.00% |
Radioactivity | 95.00% |
Sediment | 99.00% |
Selenium | 95.00% |
Silicate | 89.00% |
Silver | 97.00% |
Sodium | 94.00% |
Strontium | 97.00% |
Sulfate | 95.00% |
Thiosulfate | 99.00% |
Trihalomethane | 98.00% |
Volatile Organics | 95.00% |
Zinc | 97.00% |
Z, 4-D | 95.00% |
Design | 200 GPD | 350 GPD |
Configuration | Single Pass | Single Pass |
Feed Water Source | TDS < 1000 | TDS < 1000 |
Standard Recovery Rate | 25% | 53% |
Rejection and Flow Rates | ||
Nominal Salt Rejection % | 97.5 | 97.5 |
Permeate Flow* gpm (lpm) | 0.13 | 0.24 |
Concentrate Flow gpm (lpm) | 0.39 | 0.21 |
Connections | ||
Feed inch | 3/8" Tube | 3/8" Tube |
Permeate inch | 3/8" Tube | 3/8" Tube |
Concentrate inch | 1/4" Tube | 1/4" Tube |
Membranes | ||
Membranes(s) Per Vessel | 1 | 1 |
Membrane Quantity | 2 | 1 |
Membrane Size | 1.8 x 12 | 3 x 12 |
Vessels | ||
Vessel Array | 1:1 | 1 |
Vessel Quantity | 2 | 1 |
Systems Dimensions *** | ||
L x W x H inch | 17 ⅜" x 6 ½" x 34 ⅝" | 17 ⅜" x 6 ½ x 33 13 ⁄16" |
Weight lb. | 33 | 35 |
Operating Limits | ||
Maximum Feed Temperature °F (°C) | 85 (29.00) | 85 (29.00) |
Minimum Feed Temperature °F (°C) | 40 (4.44) | 40 (4.44) |
Maximum Ambient Temperature °F (°C) | 120 (48.89) | 120 (48.89) |
Minimum Ambient Temperature °F (°C) | 40 (4.44) | 40 (4.44) |
Maximum Feed Pressure psi | 85 | 85 |
Minimum Feed Pressure psi | 45 | 45 |
Maximum Operating Pressure psi | 120 | 120 |
Maximum SDI Rating SDI | < 3 | < 3 |
Maximum Free Chlorine ppm | 0 | 0 |
Maximum TDS ppm | 1000 | 1000 |
Maximum Hardness gpg | 10 | 10 |
Maximum pH (Continuous) | 11 | 11 |
Minimum pH (Continuous) | 3 | 3 |
Maximum Turbidity NYU | 1 | 1 |
Design | 500 GPD | 750 GPD |
Configuration | Single Pass | Single Pass |
Feed Water Source | TDS < 1000 | TDS < 1000 |
Standard Recovery Rate | 50% | 50% |
Rejection and Flow Rates | ||
Nominal Salt Rejection % | 97.5 | 97.5 |
Permeate Flow* gpm (lpm) | 0.35 | 0.52 |
Concentrate Flow gpm (lpm) | 0.35 | 0.52 |
Connections | ||
Feed inch | 3/8" Tube | 3/8" Tube |
Permeate inch | 3/8" Tube | 3/8" Tube |
Concentrate inch | 1/4" Tube | 1/4" Tube |
Membranes | ||
Membranes(s) Per Vessel | 1 | 1 |
Membrane Quantity | 2 | 2 |
Membrane Size | 3 x 12 | 3 x 12 |
Vessels | ||
Vessel Array | 1 | 1:1 |
Vessel Quantity | 1 | 2 |
Systems Dimensions *** | ||
L x W x H inch | 20 15⁄16" x 6½" x 3313⁄16" | 20 13⁄16" x 6½" x 37⅞" |
Weight lb. | 40 | 43 |
Operating Limits | ||
Maximum Feed Temperature °F (°C) | 85 (29.00) | 85 (29.00) |
Minimum Feed Temperature °F (°C) | 40 (4.44) | 40 (4.44) |
Maximum Ambient Temperature °F (°C) | 120 (48.89) | 120 (48.89) |
Minimum Ambient Temperature °F (°C) | 40 (4.44) | 40 (4.44) |
Maximum Feed Pressure psi | 85 | 85 |
Minimum Feed Pressure psi | 45 | 45 |
Maximum Operating Pressure psi | 120 | 120 |
Maximum SDI Rating SDI | < 3 | < 3 |
Maximum Free Chlorine ppm | 0 | 0 |
Maximum TDS ppm | 1000 | 1000 |
Maximum Hardness gpg | 10 | 10 |
Maximum pH (Continuous) | 11 | 11 |
Minimum pH (Continuous) | 3 | 3 |
Maximum Turbidity NYU | 1 | 1 |
